ESJOT

STANDARD SPROCKET FRONT 530

Gyártói kód50-35021-15
TermékkódCHM-ESJOT-50-35021-15
  • ESJOT front sprockets have been specially developed for the high OEM requirements and are among the best pinions on the market worldwide.
  • A special steel, high-quality case hardening and precise gearing ensure exceptionally high strength and durability - ideal for wear-intensive conditions in all areas.
  • Machined on CNC automatic lathes.
  • State-of-the-art broaching machines guarantee a precise fit on the drive shaft.
  • Concentricity and axial run-out tolerances of less than 0.1 mm.
  • 100% Made in Germany.


    • Jármű-kompatibilitás

    Válaszd ki a járműved a felső sávban, hogy ellenőrizd, illik-e ez az alkatrész.

    Ez az alkatrész 102 motorkerékpár-modellel kompatibilis.
    • CAGIVA RAPTOR 10002001–2005
    • CAGIVA V-RAPTOR 10002001–2002, 2004–2005
    • CAGIVA X-TRA RAPTOR 10002001–2005
    • KAWASAKI GPX 500 R1988–1990
    • KAWASAKI GPX 600 R1988–1999
    • KAWASAKI GPX 750 R1986–1989
    • KAWASAKI GPZ 3051983–1989
    • KAWASAKI GPZ 4001984–1987
    • KAWASAKI GPZ 600 R1985–1989
    • KAWASAKI GPZ 600 RX1987
    • KAWASAKI KZ 5501980–1983
    • KAWASAKI KZ 6501977–1981
    • KAWASAKI KZ 7501976–1980, 1982
    • KAWASAKI Z 2501981–1984
    • KAWASAKI Z 400 F1983
    • KAWASAKI Z 400 F21984–1985
    • KAWASAKI Z 400 GP1983
    • KAWASAKI Z 400 J1980–1983
    • KAWASAKI Z 4401980–1983
    • KAWASAKI Z 5001979–1980
    • KAWASAKI Z 5501980–1983
    • KAWASAKI Z 550 F1982–1984
    • KAWASAKI Z 6501978–1983
    • KAWASAKI Z 7501978–1980, 1982
    • KAWASAKI ZR 550 A1983
    • KAWASAKI ZX-6 6001990–2002
    • KAWASAKI ZXR 400 R SP1991–1996
    • KAWASAKI ZZR 4001990–2006
    • SUZUKI GS 4001977–1979
    • SUZUKI GS 400 E1978–1979
    • SUZUKI GS 400 X1977–1978
    • SUZUKI GS 4251979
    • SUZUKI GS 425 E1979
    • SUZUKI GS 425 L1979
    • SUZUKI GS 450 E1980–1982, 1988
    • SUZUKI GS 450 L1981, 1984–1987
    • SUZUKI GS 450 S1980–1981
    • SUZUKI GS 450 T1981–1983
    • SUZUKI GS 450 TX1982
    • SUZUKI GS 500 E1979–1981
    • SUZUKI GS 5501977–1979
    • SUZUKI GS 550 E1978–1980, 1983–1985
    • SUZUKI GS 550 L1979–1983, 1985–1986
    • SUZUKI GS 550 M1981–1983
    • SUZUKI GS 550 T1981
    • SUZUKI GS 650 E1981–1982
    • SUZUKI GSF 12001996–2006
    • SUZUKI GSF 1200 ABS2006
    • SUZUKI GSF 1200 S1996–2006
    • SUZUKI GSF 1200 S ABS1997–2000, 2006
    • SUZUKI GSF 1200 SZ2005
    • SUZUKI GSF 1250 ABS2007–2012
    • SUZUKI GSF 1250 S2007–2010
    • SUZUKI GSF 1250 S ABS2007–2016
    • SUZUKI GSF 6001995–2004
    • SUZUKI GSF 600 S1996–2004
    • SUZUKI GSF 6502005–2006
    • SUZUKI GSF 650 S2005–2006
    • SUZUKI GSF 650 S ABS2005–2006
    • SUZUKI GSX 1100 F1988–1996
    • SUZUKI GSX 12001999–2000
    • SUZUKI GSX 1250 F ABS2011–2016
    • SUZUKI GSX 1300 R1999–2007
    • SUZUKI GSX 1300 RZ2003, 2006–2007
    • SUZUKI GSX 14002001–2007
    • SUZUKI GSX 400 E1980–1987
    • SUZUKI GSX 400 S1980–1981, 1983–1987
    • SUZUKI GSX 550 E1983–1987
    • SUZUKI GSX 550 EF1984–1987
    • SUZUKI GSX 550 ES1983–1987
    • SUZUKI GSX 600 F1988–2006
    • SUZUKI GSX 7501998–2003
    • SUZUKI GSX 750 E1980–1982
    • SUZUKI GSX 750 EF1984–1986
    • SUZUKI GSX 750 EG1980
    • SUZUKI GSX 750 ES1983–1986
    • SUZUKI GSX 750 F1989–2006
    • SUZUKI GSX-R 10002001–2008
    • SUZUKI GSX-R 11001986–1998
    • SUZUKI GSX-R 7501985–1997
    • SUZUKI GSX-R 750 R1986
    • SUZUKI RF 600 R1993–1996
    • SUZUKI RF 900 R1994–1997
    • SUZUKI RG 5001986–1989
    • SUZUKI SV 10002003–2005
    • SUZUKI SV 1000 S2003–2007
    • SUZUKI SV 1000 SZ2006
    • SUZUKI TL 1000 R1998–2002
    • SUZUKI TL 1000 S1997–2000
    • SUZUKI VZ 8001997–2004
    • SUZUKI XN 650 XN 851983–1985
    • YAMAHA FZR 5001989–1990
    • YAMAHA FZR 6001989–1993
    • YAMAHA FZR 600 R1990–1999
    • YAMAHA FZS 6001998–2003
    • YAMAHA FZS 600 S2000–2001
    • YAMAHA RD 2501975
    • YAMAHA RD 3501973–1975
    • YAMAHA SR 5001978–1991
    • YAMAHA TX 5001973–1974
    • YAMAHA XS 5001975–1978
    • YAMAHA YZF 600 R1996–2002, 2005–2007
    Készleten
    15 db készleten
    Szállítás 1-3 munkanapon belül
    RON 55.96
    • Biztonságos online fizetésA kártyás fizetéseket biztonságosan a Stripe dolgozza fel.
      stripe
    • Fizess részletekben a KlarnávalVálaszd a Klarnát a fizetésnél.
      Klarna.

    Specificații

    Specificații

    TypeCountershaft
    UnitsEach
    MaterialSteel 16MnCr5
    Chain Size530
    Tooth Count15
    Color/FinishNatural
    Product NameSprocket
    Riding StyleStreet
    Research ValueFinalized
    Mounting PositionFront
