WOSSNER

Piston Kit

Manufacturer Code4092DA
Product CodeCHM-WOSSNER-4092DA
  • Pistons are made with high quality, permanent skirt coating to reduce friction and piston rock for quiet and improved performance
  • Optimized machining for lightness, as well as maintained strength in key areas such as crown and skirt wall cross section
  • Forged from aerospace grade aluminum alloy
  • Piston kit includes piston, rings, pin and clips


    • Double bridge forging. 3D crown. Kit Includes: • Piston #4092DA • Ring Set #RIK97.00/2 • Wrist Pin #WP072-SP • Retaining Clips #CW18
    On demand
    Delivery time determined after consultation
    RON 1,374.14
    • Secure online paymentCard payments are processed securely by Stripe.
      stripe
    • Pay in instalments with KlarnaChoose Klarna at checkout.
      Klarna.

    Specificații

    Specificații

    TypeGas Ported| Two Ring Design
    ModelStandard Series
    StyleStandard Size A
    UnitsKit
    Bore Size97,00 mm
    Engine Type4-Stroke
    Piston Size96,96 mm
    Displacement450 cc
    Product NamePiston Kit
    Riding StyleOff-Road
    Stroke Length60,80 mm
    Research ValueFinalized
    Bore - OversizeStandard
    Piston MaterialAluminum Alloy| Forged
    Bore Size Metric97.00 mm
    Compression Ratio13,0:1
    Piston Size Metric96.96 mm
    Stroke Length Metric60.80 mm
    Bore - Oversize MetricStandard
    Compression Ratio Imperial13.0:1
