WOSSNER

Piston Kit

Manufacturer Code8952DA
Product CodeCHM-WOSSNER-8952DA
  • Forged Piston: Made from aerospace-grade aluminum alloy using a closed-die forging process, which aligns the grain structure for high tensile strength and fatigue resistance
  • Piston Skirt Coating: Most kits feature a specialized dry-lute or molybdenum disulfide surface coating on the skirts to reduce friction, prevent scuffing, and ease the break-in process
  • Piston Rings: High-quality piston rings designed to match the specific thermal expansion and sealing requirements of the piston
  • Wirst Pin: Precision-machined steel pin
  • Circlips: Secure clips to keep the wristpin in place


    • Double bridge forging. Two ring design. Kit Includes: • Piston #8952DA • Ring Set #RIK79.00D • Wrist Pin #WP070-SP • Retaining Clips #CW16

    Vehicle fitment

    Select your vehicle in the bar above to check if this part fits.

    This part is compatible with 2 motorcycle models.
    • HONDA CRF 250 R2018–2019
    • HONDA CRF 250 RX2019
    In stock
    3 in stock
    Delivery in 1-3 business days
    RON 1,296.55
    • Secure online paymentCard payments are processed securely by Stripe.
      stripe
    • Pay in instalments with KlarnaChoose Klarna at checkout.
      Klarna.

    Specificații

    Specificații

    ModelPremium Series
    UnitsKit
    Bore Size79,00 mm
    Engine Type4-Stroke
    Piston SizeStandard Size A
    Displacement250 cc
    Product NamePiston Kit
    Riding StyleOff-Road
    Ring MaterialCast| Nitride Coated| Steel
    Skirt CoatingMolybdenum Disulphite
    Stroke Length50,90 mm
    Research ValueFinalized
    Piston Diameter78,96 mm
    Piston MaterialAluminum Alloy| Forged
    Compression Ratio14,0:1
