VERTEX

Piston Kit (Forged High Compression)

Manufacturer Code24382B
Product CodeCHM-VERTEX-24382B
  • Pro HC - Forged piston developed with Vertex technology and high compression
  • All pistons are heat-treated with a T-5 hardening and tempering cycle
  • Piston skirts are coated with a high-tech Molybdenum Disulphite coating for faster break-in time and increased piston life
  • Forged pistons are forged from 2618 aluminum for superior strength and durability
  • Due to the higher compression, power and torque can be improved across entire rpm range
  • Kits include piston, rings, wrist pin and circlips
  • Replacement two-stroke piston rings sold individually; four-stroke piston rings sold as a set


    • Compression: 13,85:1

    Vehicle fitment

    Select your vehicle in the bar above to check if this part fits.

    This part is compatible with 4 motorcycle models.
    • FANTIC XEF 2502022–2025
    • YAMAHA WR 250 F2020–2022
    • YAMAHA YZ 250 F2019–2022
    • YAMAHA YZ 250 FX2020–2022
    In stock
    4 in stock
    Delivery in 1-3 business days
    RON 1,709.44
    • Secure online paymentCard payments are processed securely by Stripe.
      stripe
    • Pay in instalments with KlarnaChoose Klarna at checkout.
      Klarna.

    Specificații

    Specificații

    StyleForged High Compression
    UnitsKit
    Bore Size77,00 mm
    Engine Type4-Stroke
    Piston SizeStandard Size B
    Displacement250 cc
    Product NamePiston Kit
    Riding StyleOff-Road
    Ring MaterialNitride Coated| Steel
    Skirt CoatingMoly Coated
    Research ValueFinalized
    Piston Diameter76,96 mm
    Piston MaterialAluminum Alloy| Forged
