WISECO

Piston Kit Forged Series for 4-Stroke

Manufacturer CodeW4576M07900
Product CodeCHM-WISECO-W4576M07900
  • Forged 4-stroke piston is designed for each specific engine application and built to the tightest tolerances for the ultimate combination of performance and strength
  • Dedicated forgings allow for optimized strength-to-weight ratio
  • Ideal for multiple purpose riding
  • Kit includes piston, wrist pin, rings and circlips


    • Kit Includes: • 1x Piston • 1x Ring Set #3110XG • 1x Wrist Pin #S520 • 1x Circlip Set #CW20

    Vehicle fitment

    Select your vehicle in the bar above to check if this part fits.

    This part is compatible with 4 motorcycle models.
    • SUZUKI DR 3501990–1998
    • SUZUKI DR 350 S1990–1994
    • SUZUKI DR 350 SE1994–1999
    • SUZUKI DR 350 SH1992–1994
    In stock
    4 in stock
    Delivery in 1-3 business days
    RON 959.60
    • Secure online paymentCard payments are processed securely by Stripe.
      stripe
    • Pay in instalments with KlarnaChoose Klarna at checkout.
      Klarna.

    Specificații

    Specificații

    ModelForged Series
    UnitsKit
    Bore Size79,00 mm
    Engine Type4-Stroke
    Displacement349 cc
    Product NamePiston Kit
    Riding StyleAdventure Touring / Dual-Sport
    Skirt CoatingNon-Coated
    Stroke Length71,20 mm
    Research ValueFinalized
    Bore - OversizeStandard
    Piston Diameter78,95 mm
    Piston MaterialForged 2618 Aluminum
    Bore Size Metric79.00 mm
    Compression Ratio10,5:1
    Stroke Length Metric71.20 mm
    Bore - Oversize MetricStandard
    Piston Diameter Metric78.95 mm
    Compression Ratio Imperial10.5:1
