HASTINGS

Replacement Piston Rings

Manufacturer CodeWG1254795|2M5069
Product CodeCHM-HASTINGS-WG1254795|2M5069
  • Includes top compression rings, second compression rings, and oil control rings
  • Top Compression Rings are Barrel Face
  • Helps in the the heat transfer process between the piston and cylinder wall
  • Controls combustion chamber gases allowing the piston to transfer the energy of the expanding combustion gases, to the crankshaft
  • Second Compression Ring are Napier
  • Reverse twist ring along with a taper-machined ring face duplicates the OD bottom side scraping edge of a positive twist torsional ring
  • Promotes side sealing that prevents oil from being forced under and behind the ring resulting in better oil economy
  • Oil Control Rings are Three Piece Flex Vent
  • Three-piece design allows rails to be manufactured with a small cross sectional area for better conformability to bore
  • Provides uniform pressure through four steel rails and two expanders assuring positive oil control
  • Made in the USA
  • Includes enough rings for two pistons (unless noted).
  • Two rings per groove, except for the rails that will be two rail rings per one expander ring.


    • Must order two sets for a complete motor. Kit Includes: • 1x Top Compression Ring • 1x Second Compression Ring • 1x Expansion Ring • 2x Rail Rings

    Vehicle fitment

    Select your vehicle in the bar above to check if this part fits.

    This part is compatible with 13 motorcycle models.
    • HARLEY DAVIDSON XL 1200 C2004–2020
    • HARLEY DAVIDSON XL 1200 CA ABS2014–2016
    • HARLEY DAVIDSON XL 1200 C ABS2014–2020
    • HARLEY DAVIDSON XL 1200 CB ABS2014–2017
    • HARLEY DAVIDSON XL 1200 CX2018–2020
    • HARLEY DAVIDSON XL 1200 CX ABS2018–2020
    • HARLEY DAVIDSON XL 1200 NS2021
    • HARLEY DAVIDSON XL 1200 NS ABS2018–2021
    • HARLEY DAVIDSON XL 1200 T2018–2019
    • HARLEY DAVIDSON XL 1200 T ABS2018–2020
    • HARLEY DAVIDSON XL 1200 X2018–2022
    • HARLEY DAVIDSON XL 1200 X ABS2018–2022
    • HARLEY DAVIDSON XL 1200 XS ABS2018–2020
    In stock
    15 in stock
    Delivery in 1-3 business days
    RON 140.39
    • Secure online paymentCard payments are processed securely by Stripe.
      stripe
    • Pay in instalments with KlarnaChoose Klarna at checkout.
      Klarna.

    Specificații

    Specificații

    StyleReplacement
    UnitsSet
    Product NamePiston Ring Set
    Riding StyleStreet
    Ring MaterialMoly Coated
    Research ValueFinalized
    Bore - OversizeStandard
    Bore Size Imperial3.498"
    Bore - Oversize ImperialStandard
