MAGNUM SHIELDING

1-1/4" Viking Handlebar

Cod Producător4HB-0414
Cod ProdusCHM-MAGNUMSH-4HB-0414
  • Patented Viking Handlebar internal design guarantees easy installations of complete wiring harnesses
  • Without taking away from the clean look of the peak, the novel design creates enough room to allow the complete wiring harness with factory vinyl covering and the terminal connections, along with their respective shrink sleeves, to easily pass through without chaffing
  • Using a unique flaring process, the burr-free internal radius creates a generous pocket of additional clearance within the troublesome peak of the handlebar
  • To make wiring installations even easier, Magnum preloads the bars with E-Z pull-thru plastic woven sleeving
  • Insert the wiring harness into the sleeving and pull through, it’s that simple
  • Manufactured with the highest quality construction, including smooth, round CNC mandrel bends, machined control mounts (not swaged), plus burr-free internal wiring holes, electronic throttle control slots, and high luster finishes for an unsurpassed appearance
  • Has 1-1/4" diameter, 1” diameter center sections, 3-1/2” on-center knurling, and works with standard controls, including hydraulic clutches
  • Not for use with stock risers or handlebar clamp/gauge mount clamp on 883C and 1200C models.
  • Viking handlebars have a 1" diameter center section and fit 1" risers. Models originally equipped with handlebars larger than 1" will require changing the risers to a 1" ID version.


    • Compatibilitate vehicul

    Selectează-ți vehiculul în bara de sus pentru a verifica dacă această piesă se potrivește.

    Această piesă este compatibilă cu 71 modele de motociclete.
    • HARLEY DAVIDSON FLH 1868 ABS2021
    • HARLEY DAVIDSON FLHT 13401996–1998
    • HARLEY DAVIDSON FLHT 14501999–2006
    • HARLEY DAVIDSON FLHT 15842007–2010
    • HARLEY DAVIDSON FLHT 1584 ABS2008–2010
    • HARLEY DAVIDSON FLHT 1750 ABS2019–2022
    • HARLEY DAVIDSON FLHTC 13401996–1998
    • HARLEY DAVIDSON FLHTC 14502002–2005
    • HARLEY DAVIDSON FLHTC 15842007–2011
    • HARLEY DAVIDSON FLHTC 1584 ABS2009–2011
    • HARLEY DAVIDSON FLHTC 16902012–2013
    • HARLEY DAVIDSON FLHTC 1690 ABS2011–2013
    • HARLEY DAVIDSON FLHTCI 1340 EFI1996–1998
    • HARLEY DAVIDSON FLHTCI 1450 EFI1999–2000, 2003–2006
    • HARLEY DAVIDSON FLHTCSE 1690 EFI2004
    • HARLEY DAVIDSON FLHTCSE2 1690 EFI2005
    • HARLEY DAVIDSON FLHTCU 13401996–1997
    • HARLEY DAVIDSON FLHTCU 15842007, 2009–2011
    • HARLEY DAVIDSON FLHTCU 1584 ABS2008–2011
    • HARLEY DAVIDSON FLHTCU 16902012–2013
    • HARLEY DAVIDSON FLHTCU 1690 ABS2012–2016
    • HARLEY DAVIDSON FLHTCU 1750 ABS2017–2019
    • HARLEY DAVIDSON FLHTCUI 1340 EFI1996–1998
    • HARLEY DAVIDSON FLHTCUI 1450 EFI1999–2006
    • HARLEY DAVIDSON FLHTCUL 1690 ABS2015–2016
    • HARLEY DAVIDSON FLHTCUSE 16902006
    • HARLEY DAVIDSON FLHTCUSE2 18002007
    • HARLEY DAVIDSON FLHTCUSE3 1800 ABS2008
    • HARLEY DAVIDSON FLHTCUSE4 1800 ABS2009
    • HARLEY DAVIDSON FLHTCUSE5 1800 ABS2010
    • HARLEY DAVIDSON FLHTCUSE6 1800 ABS2011
    • HARLEY DAVIDSON FLHTCUSE7 1800 ABS2012
    • HARLEY DAVIDSON FLHTCUSE8 1800 ABS2013
    • HARLEY DAVIDSON FLHTCUTG 16902009–2016
    • HARLEY DAVIDSON FLHTCUTG 17502017–2018
    • HARLEY DAVIDSON FLHTCUTG 1750 ABS2019
    • HARLEY DAVIDSON FLHTCUTG 1868 ABS2020–2022
    • HARLEY DAVIDSON FLHTCUTGSE 1923 ABS2020–2022
    • HARLEY DAVIDSON FLHTI 1450 EFI2004–2006
    • HARLEY DAVIDSON FLHTK 1584 ABS2010–2011
    • HARLEY DAVIDSON FLHTK 1690 ABS2011–2016
    • HARLEY DAVIDSON FLHTK 1750 ABS2017–2018
    • HARLEY DAVIDSON FLHTK 1868 ABS2019–2022
    • HARLEY DAVIDSON FLHTKL 1690 ABS2015–2016
    • HARLEY DAVIDSON FLHTKL 1750 ABS2017–2018
    • HARLEY DAVIDSON FLHTKL 1868 ABS2019
    • HARLEY DAVIDSON FLHTKSE 1800 ABS2014–2016
    • HARLEY DAVIDSON FLHTKSE 1868 ABS2017
    • HARLEY DAVIDSON FLHTKSE 1923 ABS2018–2021
    • HARLEY DAVIDSON FLHX 14502006
    • HARLEY DAVIDSON FLHX 15842007–2011
    • HARLEY DAVIDSON FLHX 1584 ABS2008–2011
    • HARLEY DAVIDSON FLHX 16902011–2016
    • HARLEY DAVIDSON FLHX 1690 ABS2011–2016
    • HARLEY DAVIDSON FLHX 17502017–2019
    • HARLEY DAVIDSON FLHX 1750 ABS2017–2022
    • HARLEY DAVIDSON FLHXI 1450 EFI2006
    • HARLEY DAVIDSON FLHXS 1690 ABS2014–2016
    • HARLEY DAVIDSON FLHXS 1750 ABS2017–2018
    • HARLEY DAVIDSON FLHXS 1868 ABS2019–2022
    • HARLEY DAVIDSON FLHXSE 1800 ABS2010, 2015–2016
    • HARLEY DAVIDSON FLHXSE 1868 ABS2017
    • HARLEY DAVIDSON FLHXSE 1923 ABS2018–2022
    • HARLEY DAVIDSON FLHXSE2 1800 ABS2011
    • HARLEY DAVIDSON FLHXSE3 1800 ABS2012
    • HARLEY DAVIDSON FLHXST 1923 ABS2022
    • HARLEY DAVIDSON FLHXXX 16902010–2011
    • HARLEY DAVIDSON FLRT 16902015–2016
    • HARLEY DAVIDSON FLRT 17502017–2018
    • HARLEY DAVIDSON FLRT 1750 ABS2019
    • HARLEY DAVIDSON FLRT 1868 ABS2020–2022
    La comandă
    Termenul de livrare se stabilește după consultare
    RON 2,741.50
    • Plată online securizatăPlățile cu cardul sunt procesate în siguranță prin Stripe.
      stripe
    • Plătește în rate cu KlarnaAlege Klarna la finalizarea comenzii.
      Klarna.

    Specificații

    Specificații

    UnitsEach
    Width89,5 cm (35-1/4")
    Height35,5 cm (14")
    End Rise35,5 cm (14")
    FeaturesFor Hydraulic Clutch| Knurled Center| Notched for Throttle-By-Wire| Pre-Drilled
    MaterialSteel
    Type/BendApe Hanger| Bagger| Viking
    Base ColorBlack
    Base FinishGloss
    Center Width30,5 cm (12")
    Color/FinishBlack| Gloss
    Product NameHandlebar
    Riding StyleStreet
    Width Metric89.5 cm
    Height Metric35.5 cm
    Clamping Width88,9 mm (3-1/2")
    Pullback/Sweep26,5 cm (10-1/2")
    Research ValueFinalized
    Width Imperial35-1/4"
    End Rise Metric35.5 cm
    Height Imperial14"
    Clamping Diameter25,4 mm (1")
    Controls Diameter25,4 mm (1")
    End Rise Imperial14"
    Handlebar Diameter32 mm (1-1/4")
    Center Width Metric30.5 cm
    Center Width Imperial12"
    Clamping Width Metric88.9 mm
    Pullback/Sweep Metric26.5 cm
    Clamping Width Imperial3-1/2"
    Pullback/Sweep Imperial10-1/2"
    Clamping Diameter Metric25.4 mm
    Controls Diameter Metric25.4 mm
    Handlebar Diameter Metric32 mm
    Clamping Diameter Imperial1"
    Controls Diameter Imperial1"
    Handlebar Diameter Imperial1-1/4"
