DRAG SPECIALTIES

Custom Springer Forks

Cod ProducătorMU35214
Cod ProdusCHM-DRAGSPEC-MU35214
  • Economical alternative to a shock dampened-type Springer
  • Fully assembled with an in-line top bracket without a built-in rake
  • The standard length Springer (31" measured from top bearing to the axle) is comparable to a standard-length FXST front end
  • 1" O.D. steering stem designed for Timken® type bearings
  • Both rear legs are threaded for right or left brakes
  • The 3/4" O.D. axle kit includes a brake mount pivot with thrust washer and hub spacers (custom spacers may be required depending on the wheel used)
  • Measures 9-1/4" between Rockers
  • Riser mounts are on 4-3/4" centers and threaded 1/2"-20
  • Requires wheel compatible with 3/4" O.D. axle
  • These Springers are measured from the bottom of the top tree to the center of the axle
  • Springers do not accept spotlight bars; no fender mounts.


    • These spring forks will not fit European models. The standard length Springer (31" measured from top bearing to the axle) is comparable to a standard-length FXST front end.

    Compatibilitate vehicul

    Selectează-ți vehiculul în bara de sus pentru a verifica dacă această piesă se potrivește.

    Această piesă este compatibilă cu 86 modele de motociclete.
    • HARLEY DAVIDSON FLS 16902012–2013
    • HARLEY DAVIDSON FLS 1690 ABS2012–2014
    • HARLEY DAVIDSON FLST 13401987–1990
    • HARLEY DAVIDSON FLST 14502006
    • HARLEY DAVIDSON FLSTC 13401988–1990, 1993, 1995–1999
    • HARLEY DAVIDSON FLSTC 14502002–2003, 2005–2006
    • HARLEY DAVIDSON FLSTC 15842009–2011
    • HARLEY DAVIDSON FLSTC 16902012
    • HARLEY DAVIDSON FLSTC 1690 ABS2013
    • HARLEY DAVIDSON FLSTCI 1450 EFI2002–2006
    • HARLEY DAVIDSON FLSTF 13401992–1993, 1995–1999
    • HARLEY DAVIDSON FLSTF 14502000–2004, 2006
    • HARLEY DAVIDSON FLSTF 15842007–2010
    • HARLEY DAVIDSON FLSTF 1584 ABS2011
    • HARLEY DAVIDSON FLSTF 16902012, 2014
    • HARLEY DAVIDSON FLSTF 1690 ABS2012–2013
    • HARLEY DAVIDSON FLSTFB 15842010–2011
    • HARLEY DAVIDSON FLSTFB 16902013
    • HARLEY DAVIDSON FLSTFB 1690 ABS2012–2014
    • HARLEY DAVIDSON FLSTFI 1450 EFI2001–2003, 2006
    • HARLEY DAVIDSON FLSTFSE 16902005
    • HARLEY DAVIDSON FLSTFSE2 16902006
    • HARLEY DAVIDSON FLSTN 13401993–1996
    • HARLEY DAVIDSON FLSTN 14502006
    • HARLEY DAVIDSON FLSTN 15842007–2011
    • HARLEY DAVIDSON FLSTN 1584 ABS2011
    • HARLEY DAVIDSON FLSTN 16902012
    • HARLEY DAVIDSON FLSTN 1690 ABS2013
    • HARLEY DAVIDSON FLSTNI 1450 EFI2005–2006
    • HARLEY DAVIDSON FLSTNSE 1800 ABS2014
    • HARLEY DAVIDSON FLSTS 13401997–1999
    • HARLEY DAVIDSON FLSTS 14502000–2001, 2003
    • HARLEY DAVIDSON FLSTSC 14502005–2006
    • HARLEY DAVIDSON FLSTSC 15842007
    • HARLEY DAVIDSON FLSTSCI 1450 EFI2006
    • HARLEY DAVIDSON FLSTSE 18002010
    • HARLEY DAVIDSON FLSTSE2 18002011
    • HARLEY DAVIDSON FLSTSE2 1800 ABS2011
    • HARLEY DAVIDSON FLSTSE3 1800 ABS2012
    • HARLEY DAVIDSON FLSTSI 1450 EFI2003
    • HARLEY DAVIDSON FXR 13401986–1993
    • HARLEY DAVIDSON FXR 1340 II1984
    • HARLEY DAVIDSON FXR2 13401999
    • HARLEY DAVIDSON FXRD 13401986
    • HARLEY DAVIDSON FXRDG 13401984
    • HARLEY DAVIDSON FXRP 13401984
    • HARLEY DAVIDSON FXRS 13401984–1985, 1987, 1990–1992
    • HARLEY DAVIDSON FXRS CON. 13401990, 1992–1993
    • HARLEY DAVIDSON FXRS-SP 13401987–1993
    • HARLEY DAVIDSON FXRT 13401984–1985, 1987–1988, 1992
    • HARLEY DAVIDSON FXS 15842011
    • HARLEY DAVIDSON FXS 1584 ABS2011
    • HARLEY DAVIDSON FXS 16902012–2013
    • HARLEY DAVIDSON FXS 1690 ABS2013
    • HARLEY DAVIDSON FXSB 13401984–1985
    • HARLEY DAVIDSON FXSB 16902013
    • HARLEY DAVIDSON FXSB 1690 ABS2013
    • HARLEY DAVIDSON FXSBSE 1800 ABS2013
    • HARLEY DAVIDSON FXSBSE2 1800 ABS2014
    • HARLEY DAVIDSON FXST 13401985–1986, 1988–1990
    • HARLEY DAVIDSON FXST 14502000–2001, 2003–2006
    • HARLEY DAVIDSON FXST 15842007
    • HARLEY DAVIDSON FXSTB 13401998–1999
    • HARLEY DAVIDSON FXSTB 14502000, 2003–2006
    • HARLEY DAVIDSON FXSTB 15842007, 2009
    • HARLEY DAVIDSON FXSTBI 1450 EFI2003–2006
    • HARLEY DAVIDSON FXSTC 13401986, 1988–1989, 1991–1994, 1996–1997
    • HARLEY DAVIDSON FXSTC 15842007–2010
    • HARLEY DAVIDSON FXSTD 14502000–2003, 2005–2006
    • HARLEY DAVIDSON FXSTD 15842007
    • HARLEY DAVIDSON FXSTDI 1450 EFI2001–2005
    • HARLEY DAVIDSON FXSTDSE 15502003
    • HARLEY DAVIDSON FXSTI 1450 EFI2003–2005
    • HARLEY DAVIDSON FXSTS 13401988, 1990–1992, 1994–1999
    • HARLEY DAVIDSON FXSTS 14502001–2003, 2006
    • HARLEY DAVIDSON FXSTSB 13401995–1997
    • HARLEY DAVIDSON FXSTSI 1450 EFI2003–2006
    • HARLEY DAVIDSON FXSTSSE 18002007
    • HARLEY DAVIDSON FXSTSSE3 18002009
    • HARLEY DAVIDSON XL 1200 C1996–2003
    • HARLEY DAVIDSON XL 1200 S1996–1998, 2001–2003
    • HARLEY DAVIDSON XL 883 C1998–2001, 2003
    • HARLEY DAVIDSON XL 883 R2002–2003
    • HARLEY DAVIDSON XLH 11001986–1987
    • HARLEY DAVIDSON XLH 12001991–1996, 1998, 2001, 2003
    • HARLEY DAVIDSON XLH 8831987–2003
    La comandă
    Termenul de livrare se stabilește după consultare
    RON 4,349.22
    • Plată online securizatăPlățile cu cardul sunt procesate în siguranță prin Stripe.
      stripe
    • Plătește în rate cu KlarnaAlege Klarna la finalizarea comenzii.
      Klarna.

    Specificații

    Specificații

    UnitsEach
    FeaturesLifts 4.00"
    Color/FinishChrome
    Product NameSpringer
    Riding StyleStreet
    Research ValueFinalized
