KIBBLEWHITE

Cylinder Head Service Kit

Cod Producător30-33330
Cod ProdusCHM-KIBBLEWH-30-33330
  • Kit includes complete top end gasket kit, full set of KPMI® standard valves, high performance titanium spring kit, complete set of valve guides, and Viton® valve stem seals
  • Top end gasket kit includes base gaskets, engine case gaskets, exhaust gaskets, head gaskets and necessary o-rings and washers
  • C630 valve guides are a blend of copper, nickel, and aluminum
  • C674 valve guides are a softer Manganese that are easily reamed
  • Black Diamond™ valves are a one pieced forged stainless steel valve that are impregranted by a special German process to improve wear properties and reduce friction
  • White Diamond® valves are fully CNC machined from one-piece forging of either EV8 Stainless Steel or Inconel-751 material, and are hard chromed with a 360° anode to produce the highest possible grade of a hard chrome finish


    • Includes: • 2x Intake Titanium Retainers • 2x Intake CrSi Valve Springs • 2x Intake H.T. Steel Basewashers • 2x Exhaust Titanium Retainers • 2x Exhaust CrSi Valve Springs • 2x Exhaust H.T. Steel Basewashers • 2x Intake Standard White Diamond® Valves • 2x Exhaust Standard White Diamond® Valves (Inconel®) • 2x Intake Standard C630 Valve Guides • 2x Exhaust Standard C630 Valve Guides • 2x Intake Viton Seals • 2x Exhaust Viton Seals • 1x Top End Gasket Kit

    Compatibilitate vehicul

    Selectează-ți vehiculul în bara de sus pentru a verifica dacă această piesă se potrivește.

    Această piesă este compatibilă cu 3 modele de motociclete.
    • HONDA CRF 450 R2017–2021
    • HONDA CRF 450 RWE2019–2021
    • HONDA CRF 450 RX2017–2021
    La comandă
    Termenul de livrare se stabilește după consultare
    RON 3,913.37
    • Plată online securizatăPlățile cu cardul sunt procesate în siguranță prin Stripe.
      stripe
    • Plătește în rate cu KlarnaAlege Klarna la finalizarea comenzii.
      Klarna.

    Specificații

    Specificații

    ModelWhite Diamond®
    UnitsKit
    MaterialC630 Bronze
    ApplicationExhaust| Intake
    Spring LiftIntake 0,440" , Exhaust 0,405"
    Product NameCylinder Head Service Kit
    Riding StyleOff-Road
    Research ValueFinalized
    Collar MaterialTitanium
    Valve Seat HeightIntake 1,340", Exhaust 1,360"
    Spring Lift ImperialIntake 0.440", Exhaust 0.405"
    Spring Open PressureIntake 162 lb, Exhaust 220 lb
    Spring Seat PressureIntake 50 lb, Exhaust 90 lb
    Valve Seat Height ImperialIntake 1.340", Exhaust 1.360"
