WOSSNER

Piston Kit for 4 Stroke

Manufacturer Code8608DA
Product CodeCHM-WOSSNER-8608DA
  • Enhanced piston pin oiling slots, radial boss machining, and annular grooves for improved wrist pin lubrication
  • Lightweight piston with a tight piston wall clearance for a quieter running engine
  • Skirt coated for reduced friction and improved break in performance
  • Ring land treatment for improved ring seal and oil control
  • Double bridged forging design where noted
  • Kit includes piston, rings, wrist pin and pin locks


    • Double bridge forging. Two ring design. Kit Includes: • Piston #8608DA • Ring Set #RIK96.00E • Wrist Pin #WP071-SP • Retaining Clips #CW19

    Vehicle fitment

    Select your vehicle in the bar above to check if this part fits.

    This part is compatible with 2 motorcycle models.
    • HONDA CRF 450 R2005–2008
    • HONDA CRF 450 X2005–2013
    In stock
    1 in stock
    Delivery in 1-3 business days
    RON 1,296.55
    • Secure online paymentCard payments are processed securely by Stripe.
      stripe
    • Pay in instalments with KlarnaChoose Klarna at checkout.
      Klarna.

    Specificații

    Specificații

    ModelPremium Series
    StyleStandard Size A
    UnitsKit
    Bore Size96,00 mm
    Engine Type4-Stroke
    Piston Size95,96 mm
    Product NamePiston Kit
    Riding StyleOff-Road
    Stroke Length62,10 mm
    Research ValueFinalized
    Bore - OversizeStandard
    Piston MaterialAluminum Alloy| Forged
    Bore Size Metric96.00 mm
    Compression Ratio12,0:1
    Piston Size Metric95.96 mm
    Stroke Length Metric62.10 mm
    Bore - Oversize MetricStandard
    Compression Ratio Imperial12.0:1
